| system |
ActiveStor 14 |
ActiveStor 14T |
| Workload suitable |
In a large configuration of SSD capacity is ideal for large and small file processing workload are mixed |
IOPS oriented workload required for the processing of small files at random. |
| maximam size |
8.3PB |
4.5PB |
| Maximum throughput |
150GB/sec |
150GB/sec |
| System maximum IOPS |
1,300,000 |
1,400,000 |
| max number of shelves |
100 |
100 |
| Shelf SPEC |
| Capacity per shelf |
81.2T or 83TB |
45TB |
| HDD |
80TB |
40TB |
| SSD |
1.2TB or 3.0TB |
4.8TB |
| SSD capacity ratio |
1.5% or 3.6% |
10.7% |
| Drive configuration |
20 x 3.5” SATA + 10 x 1.8” MLC SSD |
| ECC cache memory |
92GB |
172GB |
| Max write/Readthroughput |
1.6GB/sec / 1.5GB/sec |
1.6GB/sec / 1.5GB/sec |
| Max IOPS - 4kbfile, Random read |
11,000 |
14,000 |
| Blade configurations |
1+10, 2+9 or 3+8, Enhanced 0+11 # non Director Blade |
| Network uplinks per switch |
1 x 10GbE SFP+/CX4 or 4 x GbE copper |
| Added 10GbE Network for Director Blade |
2 x 10GbE SFP+ |
| LAG is HA (network failover) |
OK |
| Compatible InfiniBand router |
OK |
|
